Food-specific IgG testing can be performed using several laboratory technologies, the most common being ELISA (enzyme-linked immunosorbent assay) and multiplex microarray platforms. While ELISA is a well-established and reliable method for measuring individual antibodies, microarray-based assays offer several advantages when testing large panels of food antigens.

These advantages relate primarily to multiplex capacity, analytical sensitivity, antigen presentation, and sample efficiency.

1. Multiplex Testing Capability

Traditional ELISA assays typically measure one antigen per well. When testing large numbers of foods, each antigen requires a separate reaction.

For example:

  • 200 foods tested individually by ELISA would require 200 separate reactions
  • Replication for reliability further increases the number of wells required.

Microarray technology allows hundreds of food antigens to be immobilised on a single test surface, enabling simultaneous analysis of many food-specific IgG antibodies within one assay.

This multiplex format allows:

  • Large panels of foods to be assessed simultaneously
  • Consistent assay conditions across all antigens
  • Reduced inter-assay variability

2. Nitrocellulose Membrane Provides a 3D Protein Binding Surface

Microarray platforms such as FoodPrint® utilise a nitrocellulose membrane substrate, which differs significantly from the flat plastic surface used in standard ELISA plates.

Nitrocellulose provides:

  • A three-dimensional protein-binding matrix
  • Higher protein binding capacity
  • Improved antigen accessibility

This 3D structure allows antigens to be presented in a way that can enhance antibody capture compared with the two-dimensional adsorption surface used in ELISA wells.

The result is often improved analytical sensitivity and signal detection, particularly for low-abundance antibodies.

3. Optimisation of Food Protein Antigens

Microarray systems allow individual protein extracts to be carefully optimised before immobilisation.

Key optimisation steps typically include:

• Selection of appropriate protein extracts
• Control of antigen concentration
• Buffer optimisation to preserve epitope structure
• Controlled deposition of antigens onto the membrane

This optimisation helps ensure that relevant epitopes remain available for antibody binding.



Supply Life

Unlock your full potential today

Get your easy to use food intolerance test today

Discover Products

Order Now

4. Small Sample Volume Requirements

One of the major advantages of multiplex microarrays is their extremely low sample volume requirement.

Because hundreds of reactions occur simultaneously on a single membrane, only a very small amount of serum is required.

For example:

• A microarray platform can test 200+ foods using only a few microlitres of serum

By contrast, traditional ELISA testing of large panels would require significantly greater sample volumes.

This is particularly beneficial when samples are collected via capillary finger-prick sampling.

5. Built-In Replication Improves Analytical Reliability

Well-designed microarray assays often include duplicate spotting of each antigen.

This means that:

• Each food antigen is tested twice within the same assay
• Signal concordance between duplicate spots can be assessed
• Analytical reliability is improved

In contrast, ELISA replication usually requires running additional wells, increasing reagent and sample use.

6. Consistency Across the Entire Food Panel

Because all antigens are tested simultaneously on the same membrane:

• Incubation conditions are identical
• Detection reagents are identical
• Timing is identical

This helps reduce run-to-run variability that may occur when large panels are tested across multiple ELISA plates.

7. Suitability for Large-Scale Multiplex Food Panels

ELISA remains an excellent method for single-analyte diagnostics, such as infectious disease testing or hormone measurement.

However, when the goal is to analyse large numbers of food-specific antibodies simultaneously, multiplex microarray platforms offer clear operational advantages.

These include:

• Higher throughput
• Reduced sample volume requirements
• Built-in duplication for reliability
• Efficient analysis of large antigen panels

Suggested Summary Line (for Supply Life blog use)

Microarray technology allows hundreds of food antigens to be analysed simultaneously using only a very small sample, with duplicate testing and enhanced antigen presentation on a nitrocellulose membrane designed to optimise antibody detection.


Microarray vs ELISA for Food-Specific IgG Testing

Feature

Traditional ELISA Testing

FoodPrint® Microarray Technology

Testing format

Measures one antigen per well

Tests hundreds of food antigens simultaneously on a single membrane

Multiplex capability

Limited – each food requires a separate reaction

Highly multiplexed – large food panels analysed in a single assay

Sample volume required

Larger sample needed when testing many foods

Very small sample required due to multiplex design

Suitability for finger-prick sampling

More challenging with large panels due to sample volume requirements

Well suited to small capillary samples

Antigen surface

Flat plastic well surface (2D adsorption)

Nitrocellulose membrane with a 3D protein-binding structure

Antigen binding capacity

Limited protein binding surface

Higher protein binding capacity supporting enhanced antibody capture

Antigen presentation

Passive adsorption to plastic wells

Optimised deposition of food proteins onto membrane substrate

Replication of antigens

Requires additional wells to run duplicates

Each antigen printed in duplicate within the same assay

Consistency across food panel

Large panels may require multiple plates and assay runs

All foods tested simultaneously under identical assay conditions

Throughput efficiency

Lower efficiency when testing large food panels

Designed for high-throughput multiplex testing

Analytical reliability

Depends on plate replication strategy

Internal duplicate antigen spots support quality control



Key Takeaway

Microarray technology enables simultaneous analysis of hundreds of food-specific IgG antibodies using minimal sample volume, with duplicate antigen testing and a nitrocellulose membrane designed to optimise antibody detection.

Why does the membrane matter?

FoodPrint® uses a nitrocellulose membrane rather than a plastic ELISA plate.

Nitrocellulose has a three-dimensional protein-binding structure, allowing food antigens to be immobilised more effectively and improving antibody accessibility. This design supports sensitive detection of food-specific IgG antibodies across large multiplex panels.
